This is a reply for RyDarling…
You can easily install the GoZ button manually into a new Shelf in Maya. This is the mel code to do it, but first check out where are your GoZApps installed. In my case (Windows7) they are located in
C:/Users/Public/Pixologic/GoZApps
If yours are in a different location simply change those accordingly into the code. First Open the script editor, paste the code underneath, execute it (really just sourcing the procedure) and then execute the procedure itself shelf_GoZBrush. The icon will show up in the script editor and you can drag and drop it into the shelf that you prefer.
global proc shelf_GoZBrush () { global string $gBuffStr;
global string $gBuffStr0;
global string $gBuffStr1;
shelfButton
-enableCommandRepeat 1
-enable 1
-width 34
-height 34
-manage 1
-visible 1
-preventOverride 0
-align “center”
-label “GoZ”
-labelOffset 0
-font “tinyBoldLabelFont”
-image “C:/Users/Public/Pixologic/GoZApps/Maya/GoZBrush.xpm”
-image1 “C:/Users/Public/Pixologic/GoZApps/Maya/GoZBrush.xpm”
-style “iconOnly”
-marginWidth 1
-marginHeight 1
-command "source “C:/Users/Public/Pixologic/GoZApps/Maya/GoZBrushFromMaya.mel”
"
-sourceType “mel”
-actionIsSubstitute 0
-commandRepeatable 1
;
}
The code underneath is executed every time you click the GoZ shelf button
in Maya:
// ------------------------------------------
// GoZBrush from Maya script
// ------------------------------------------
// ------------------------------------------
// Global variables.
global string $GoZBrushPath = “C:/Users/Public/Pixologic/GoZBrush/”;
global string $GoZAppExt = “.exe”;
global string $GoZProjectPath;
global int $GoZDebugON = 0;
global string $gFileBaseName = “”;
global int $gFileOccurrence = 0;
global string $selObjects[];
// ------------------------------------------
// Launch an application.
// Code is different depending on PC/Mac.
global proc launchApp(string $path)
{
// On Windows:
system($path);
// On MacOSX:
//system(“open -a “”+$path+”"");
}
// ------------------------------------------
// Debug purpose…
global proc printDebug(string $text)
{
global int $GoZDebugON;
if ($GoZDebugON)
{
print($text+"
“);
}
}
// ------------------------------------------
// Decompose a fileName into [$gFileBaseName][$gFileOccurrence],
// where [$gFileBaseName] is text and $gFileOccurrence is an integer.
// For example, decompose “myFile25” into (“myFile”, 26)
global proc decomposeFileName(string $fileName)
{
global string $gFileBaseName;
global int $gFileOccurrence;
int $index;
int $count;
string $car;
$count = size($fileName);
for ($index=$count; $index>0; $index–)
{
$car = substring $fileName $index $index;
$car = match "[0-9]" $car;
if ($car == “”)
break;
}
if ($index == $count)
{
$gFileBaseName = $fileName;
$gFileOccurrence = 0;
}
else
{
if ($index > 0)
$gFileBaseName = substring $fileName 1 $index;
else
$gFileBaseName = “”;
$index++;
$car = substring $fileName $index $count;
$gFileOccurrence = $car;
}
}
// ------------------------------------------
// Tests if a GoZ name matches an object name.
// The test is performed using decomposition of both names(see decomposeFileName).
// The GoZ name matches the object name if and only if:
// 1- both names decomposition have the same base name
// 2- the occurence of GoZ name is greater or equal to the occcurrence of object name.
// For example, for object name “myFile25”:
// - “myFile25” and “myFile48” are valid GoZ names,
// - “myFile24” and “toto_en_short” are NOT valid GoZ names!
global proc int isRightGoZID(string $objectName, string $objectGoZName)
{
global string $gFileBaseName;
global int $gFileOccurrence;
string $objectGoZBaseName;
int $objectGoZOccurrence;
string $objectBaseName;
int $objectOccurrence;
decomposeFileName($objectGoZName);
$objectGoZBaseName = tolower $gFileBaseName;
$objectGoZOccurrence = $gFileOccurrence;
decomposeFileName($objectName);
$objectBaseName = tolower $gFileBaseName;
$objectOccurrence = $gFileOccurrence;
if ($objectBaseName != $objectGoZBaseName)
return 0;
if ($objectGoZOccurrence < $objectOccurrence)
return 0;
return 1;
}
// ------------------------------------------
// Simulates a sleep of some milliseconds.
// Note: as no sleep command is available, it waits “actively” for the amout of time…
global proc sleep(float $delayInSecond)
{
float $startTime;
float $ellapsedTime;
$startTime = timerX;
$ellapsedTime = timerX -st $ellapsedTime;
while ($ellapsedTime < $delayInSecond)
{
$ellapsedTime = timerX -st $ellapsedTime;
}
}
// ------------------------------------------
// Creates a new GoZ name based an an object name.
// Creation is made using the GoZ utility “GoZMakeObjectPath”,
// which ensures that the GoZ name is unique.
// Note: check if the GoZ name $name is unique consists on
// checking ZTN files in “/Users/Public/Pixologic/GoZProject/default/”,
// and verify that the file $name.ztn does not exist in that folder.
// IMPORTANT: It implies that to safely create several unique GoZ names,
// the caller should create an empty ZTN file using the unique name it returns.
global proc string createGoZID(string $objectName)
{
global string $GoZBrushPath;
global string $GoZAppExt;
string $fileName;
string $path;
int $fileId;
float $startTime;
float $ellapsedTime;
float $delay;
$fileName = $GoZBrushPath + “GoZ_ObjectPath.txt”;
$fileId = fopen $fileName "w";
fprint $fileId $objectName;
fclose $fileId;
$fileName = $GoZBrushPath + “GoZMakeObjectPath” + $GoZAppExt;
launchApp($fileName);
$fileName = $GoZBrushPath + “GoZ_ObjectPath.txt”;
$startTime = timerX;
$ellapsedTime = timerX -st $startTime;
$delay = 0.02;
while ($ellapsedTime < 2.0)
{
$fileId = fopen $fileName "r";
if ($fileId != 0)
{
$path = “”;
$path = fread $fileId $path;
fclose $fileId;
if (size($path) > size($objectName))
{
string $tokens[];
int $tokenCount;
$tokenCount = tokenize $path "/\\" $tokens;
/*
if ($tokenCount < 2)
{
printDebug(” >>>> No token found in path “” + $path + “” <<<<");
return $objectName;
}
printDebug(" >>>> " + $tokenCount + " tokens found in path “” + $path + “” <<<<");
*/
$path = $tokens[$tokenCount-1];
printDebug(" >>>> Unique GoZ ID “” + $path + “” generated for object “” + $objectName + “” <<<<");
return $path;
}
}
sleep($delay);
$delay = 0.1;
$ellapsedTime = timerX -st $startTime;
}
// If here, did not manage to find a valid path.
// As such an error is not managed, just returns $objectName which will be overwrited.
printDebug(" >>>> No unique GoZ ID generated for object “” + $objectName + “” <<<<");
return $objectName;
}
// ------------------------------------------
// Exports a GoZ object to ZBrush.
global proc int exportGoZObject(string $objectName)
{
global string $GoZBrushPath;
global string $GoZProjectPath;
global string $selObjects[];
string $maFileName;
string $ztnFileName;
string $gozName;
string $gozPath;
string $validGoZName;
string $fileName;
int $fileId;
printDebug(" Exporting object " + $objectName + “…”);
// The object already has a GoZBrushID attribute, which contains an ID of ZTN file.
if (attributeQuery -node $objectName -ex "GoZBrushID")
{
//select -r $objectName;
$gozName = getAttr($objectName + “.GoZBrushID”);
$ztnFileName = $GoZProjectPath + $gozName + “.ztn”;
printDebug(" Found GoZBrushID attribute = " + $gozName);
// There is an existing GoZ ID, but it does not match the object name.
// This can occur either after a copy or a rename of the object.
// In such a case, create a new GoZ ID matching the object name,
// and copy maps from previous ID if it still exists.
if (!isRightGoZID($objectName, $gozName))
{
// Stores previous GoZ ID.
string $oldGoZName = $gozName;
// Creates a new GoZ ID.
$gozName = createGoZID($objectName);
setAttr -type “string” ($objectName + “.GoZBrushID”) ($gozName);
printDebug(" GoZBrushID is not valid(object is a copy or was renamed) - new GoZBrushID created = " + $gozName);
// If previous ID still exists, copy maps from previous ID to new ID.
if (file -q -exists $ztnFileName)
{
printDebug(" The previous ZTN file still exists: copy the maps from previous GoZBrushID to new one!");
string $sourcePath;
string $targetPath;
// copy normal map
$sourcePath = $GoZProjectPath+ $oldGoZName + “_NM.tif”;
$targetPath = $GoZProjectPath+ $gozName + “_NM.tif”;
if (file -q -exists $sourcePath)
{
sysFile -copy $targetPath $sourcePath;
}
// copy displacement map
$sourcePath = $GoZProjectPath+ $oldGoZName + “_DM.tif”;
$targetPath = $GoZProjectPath+ $gozName + “_DM.tif”;
if (file -q -exists $sourcePath)
{
sysFile -copy $targetPath $sourcePath;
}
// copy texture map
$sourcePath = $GoZProjectPath+ $oldGoZName + “_TXTR.tif”;
$targetPath = $GoZProjectPath+ $gozName + “_TXTR.tif”;
if (file -q -exists $sourcePath)
{
sysFile -copy $targetPath $sourcePath;
}
} // End of if (file -q -exists $ztnFileName)
// Creates an empty ZTN file.
$ztnFileName = $GoZProjectPath + $gozName + “.ztn”;
$fileId = fopen $ztnFileName "w";
fclose $fileId;
} // End of if (!isRightGoZID($objectName, $gozName))
// If the GoZBrushID is the right one, verifies that the ZTN file still exists.
// If not, creates an empty one.
else if (!file -q -exists $ztnFileName)
{
// Creates an empty ZTN file.
$fileId = fopen $ztnFileName "w";
fclose $fileId;
}
} // End of if (attributeQuery -node $objectName -ex "GoZBrushID")
// The object does NOT have any GoZBrushID attribute.
else
{
string $objectHistory[];
string $historyName;
int $objectHistoryCount;
int $objectHistoryIndex;
printDebug(" No GoZBrushID found… search in the history for any GoZBrushID");
// Search in the object history for a GoZ object.
$gozName = “”;
$objectHistory = listHistory $objectName;
$objectHistoryCount = size($objectHistory);
for ($objectHistoryIndex=0; $objectHistoryIndex<$objectHistoryCount; $objectHistoryIndex++)
{
$historyName = $objectHistory[$objectHistoryIndex];
if (attributeQuery -node $historyName -ex "GoZBrushID")
{
$gozName = getAttr($historyName + “.GoZBrushID”);
$ztnFileName = $GoZProjectPath + $gozName + “.ztn”;
if (file -q -exists $ztnFileName)
{
string $msg;
int $result;
printDebug(" Found a GoZ object in the history: " + $historyName + " — GoZBrushID = " + $gozName);
// Found a GoZ object in the construction history: asks the user if we change the object name to GoZ one or not.
$msg = “The object “” + $objectName + “” is a descendant of “” + $historyName + “.GoZBrushID”.”;
$msg = $msg + "
Press OK to restore the original GoZ name “” + $gozName + “” and send the modified mesh to ZBrush for remapping.";
$result = confirmDialog -title "GoZBrush Note" -message $msg -button "OK" -button "Cancel" -defaultButton "OK" -cancelButton "Cancel" -dismissString "OK";
if ($result == “Cancel”)
{
$gozName = “”;
break;
//return 0;
}
// “Move” the GoZBrushID attribute from the history object to selected object,
// and rename the selected object to the ZTN file name.
// Note: compared to previous version, the history is NOT destroyed(not needed).
deleteAttr($historyName + “.GoZBrushID”);
addAttr -ln “GoZBrushID” -nn “GoZBrushID” -dt “string” $objectName;
setAttr -type “string” ($objectName + “.GoZBrushID”) ($gozName);
rename $objectName $gozName;
$objectName = $gozName;
break;
} // End of if (file -q -exists $ztnFileName)
else
{
deleteAttr($objectHistory[$objectHistoryIndex] + “.GoZBrushID”);
$gozName = “”;
}
} // End of if ( attributeQuery -node $objectHistory[$objectHistoryIndex] -ex "GoZBrushID" )
} // End of for ( $objectHistoryIndex=0; $objectHistoryIndex<$objectHistoryCount ; $objectHistoryIndex++)
// If no valid GoZ object was found in the history, create a new GoZ ID.
if ($gozName == “”)
{
// Creates a new GoZ ID.
$gozName = createGoZID($objectName);
addAttr -ln “GoZBrushID” -nn “GoZBrushID” -dt “string” $objectName;
setAttr -type “string” ($objectName + “.GoZBrushID”) ($gozName);
// Creates an empty ZTN file.
$ztnFileName = $GoZProjectPath + $gozName + “.ztn”;
$fileId = fopen $ztnFileName "w";
fclose $fileId;
printDebug(" nothing found in the history, create GoZBrushID"" + $gozName + “”");
}
} // End of else of if (attributeQuery -node $objectName -ex "GoZBrushID")
// All is fine now regarding the GoZBrushID, next step is exporting the object to a Maya file.
printDebug(" Exporting object “” + $objectName + “” to “” + $gozName + “.ma”");
// To avoid parametric object descriptions and any other unsupported shapes, first of all delete the construction history.
// As a result, the object will become a basic mesh.
delete -ch $objectName;
makeIdentity -apply true -t 1 -r 1 -s 1 -n 0 $objectName;
delete -ch $objectName;
// Selects only the object so that it can be exported “alone”.
select -r $objectName;
// Then exports it to a Maya file.
$maFileName = $GoZProjectPath + $gozName + “.ma”;
sysFile -delete $maFileName;
file -op “v=0” -typ “mayaAscii” -es $maFileName;
// Then reselects all the objects previously selected.
select -r $selObjects;
// Appends the GoZ object to the GoZ object list.
$gozPath = $GoZProjectPath + $gozName;
$fileName = $GoZBrushPath + “GoZ_ObjectList.txt”;
$fileId = fopen $fileName "a";
fprint $fileId $gozPath;
fprint $fileId "
“;
fclose $fileId;
printDebug(” Object path is “” + $gozPath + “”");
return 1;
}
// ------------------------------------------
// Export one or several meshes to ZBrush…
printDebug(“GoZ Maya >>> ZBrush”);
// Misc local initializations.
string $fileName;
int $selObjectCount;
int $fileId;
int $exportCount;
// Gets the path where to export Maya files.
$fileName = $GoZBrushPath + “GoZ_ProjectPath.txt”;
$fileId = fopen $fileName "r";
$GoZProjectPath = fread $fileId $GoZProjectPath;
fclose $fileId;
// Set the object selection mode and get all selected objects.
SelectTool;
changeSelectMode -component;
changeSelectMode -object;
$selObjects = ls -selection -shortNames -dagObjects -transforms; // -tail 1; $selObjectCount =size($selObjects); // Clears the GoZ object list. $fileName = $GoZBrushPath + "GoZ_ObjectList.txt"; $fileId =fopen $fileName "w"; fclose $fileId; // Exports all selected objects. printDebug("GoZ start exporting " + $selObjectCount + " selected objects:"); $exportCount = 0; for ($selObjectIndex=0; $selObjectIndex<$selObjectCount; $selObjectIndex++) $exportCount += exportGoZObject($selObjects[$selObjectIndex]); printDebug($exportCount + " GoZ objects were exported!"); // If no object was exported, shows up a dialog to ask the user to select a mesh to GoZBrush. if ($exportCount == 0) { confirmDialog -title "GoZBrush Note" -message "No mesh was exported! Please, select a mesh to GoZBrush." -button "OK" -defaultButton "OK"; } // Otherwise(at least 1 object was exported), GoZee to ZBrush. else { // Sets the right application id(Maya). $fileName = $GoZBrushPath + "GoZ_Application.txt"; $fileId =fopen $fileName “w”`;
fprint $fileId “Maya”;
fclose $fileId;
// Launch GoZBrush application.
$fileName = $GoZBrushPath + “GoZBrushFromApp” + $GoZAppExt;
launchApp($fileName);
}
small_orange_diamond
